Features:

• Precision AWG with two DAC settings
• 14-bit resolution up to 8 GSa/s
• 12-bit resolution up to 12 GSa/s
• High-speed arbitrary waveform generators
• Variable sample rate from 125 MSa/s to 8 / 12 GSa/s
• Spurious-free-dynamic range (SFDR) up to 90 dBc typical
• Up to 2 GSa arbitrary waveform memory per channel with advanced sequencing
• Analog bandwidth up to 5GHz
• Unique Performance – Unique Value
• Up to 90 dBc SFDR - Tones clearly stand out of noise (Even with thousands of tones)
• 2 GSa memory per channel - Realistic signal scenarios with long play time
• 5 GHz analog bandwidth - Mimic analog imperfections with custom ISI
• Key applications
• Radar, Satellite, Electronic Warfare, Multilevel Signals
• ADC testing (Analog Digital Converter testing), Jitter Margin Testing
• Digital Video, Noise Power Ratio Measurement, Wireless HD, HDMI, MHL
• IEEE 802.11ad, CaTV, OFDM, Software Defined Radio

Specifications:

• 5 GHz

From low-observable systems to high-density comms, testing is more realistic with precision arbitrary waveform generation. Now you can take reality to the extreme: A Keysight AWG is the source of greater fidelity, delivering high resolution and wide bandwidth – simultaneously. This unique combination lets you create signal scenarios that push your design to the limit and bring new insight to your analysis. Get bits and bandwidth – and enhance your reality.
